CED Fabrications - Designline Brand - Chilled LogoNon Standard Airflow (Cold) – Option AF1
Air In/Out Customer Side.

Wall-sited counters. When the counter is wall sited, the chilled unit air intake grill and air outlet have to be brought through the counter front fascia panel. The option air in/out to customer side is generally for use with the self help chilled well model – as assisted service chilled units are not normally located in wall sited counters. **The fixed back multideck (MDF2,3,4) does not need airflow option AF1 fitted, as it vents the air outlet through a rear worktop mounted grill, supplied as standard.

Non Standard Airflow (Cold) – Option AF2
Air In/Out Operator Side.

Free-standing counters. For aesthetic reasons, customers may not require the chilled unit air intake grill on the counter front fascia panel. (see image above).
Designline drop in chilled displays can be factory fitted with an inline fan and flexible duct to provide air in/out to operator side. This option can be used with chilled well, deli, self help/ assisted service multideck, multi-level deli. Note – 2/1 gn size units require additional counter space adjacent to the drop in location, to site the fan/duct.

Visual AF1

Non Standard Airflow KitCED Fabrications - Designline Brand - Chilled Logo

Non Standard Airflow Option - In & Out Customer SideAF1 (In/Out Customer Side Airflow)



Visual AF2

Non Standard Airflow Kit CED Fabrications - Designline Brand - Chilled Logo

Non Standard Airflow Option - In & Out Operator SideAF2 (In/Out Operator Side Airflow)



Features

Non Standard Airflow Kit (Cold)CED Fabrications - Designline Brand - Chilled Logo
Features

AF1 – In/Out Customer Side Airflow (factory fit with initial order only)

  • Non standard airflow – in / out customer side
  • Inline fan assisted ducting for removal of heat/moisture from condensing unit.
  • Suitable for wall sited counters etc.
  • Fitted with 2 metre flexible duct, with bright polished steel air intake & extract grille.

AF2 – In/Out Operator Side Airflow (factory fit with initial order only)

  • Non standard airflow – in / out operator side
  • Inline fan assisted ducting for removal of heat/moisture from condensing unit.
  • Suitable for counters where intake grille is not required on customer side fascia panel.
  • Fitted with 2 metre flexible duct, with bright polished steel air intake & extract grille.


Dimensions

Non Standard Airflow Kit (Cold)CED Fabrications - Designline Brand - Chilled Logo
Dimensions

Model

AF1 (Customer Side)

AF2 (Operator Side)

Capacity

N/A

N/A

Length (mm)

2000

2000

Width (mm)

150

150

Weight (uncrated) (kg)

0.75

0.75

Power (kW)

+ 0.07

+ 0.07

Electrical supply

See model

See model



Downloads

General Layout Drawings CED Fabrications - Designline Brand - Chilled Logo
AF1 – In/Out Customer Side Airflow







AF2 – In/Out Operator Side Airflow



Fitting Instructions

** Please see the individual Designline & Kubus models fitting Instructions, located in their ‘download’ sections for AF1 or AF2 airflow **




website AMB-DESIGNLINE-HEADER copy
page-header---D.LINE-AF2

Option AF2 (Air in/out operator side shown)
