Sterilizing-Unit---Main-ImaTOURNUS_300_rvbSterilizing Unit.
The Tournus wall mounted Sterilizing Unit is a hydraulic spray unit for low pressure cleaning and sterilizing of surfaces and floors.

desinfectionThe sterilizing unit is designed for use with 2-6 bar water pressure & comes with a separate detergent can holding frame, for supporting a 5 Lt container, max. load 10 Kg. – container not supplied. The sterilizing unit features a 15 M length of discharge hose c/w anti-shock spray gun & trigger handle.

The detergent suction hose provided (2 M length) has a weighted end filter – the lid of the detergent container can be drilled with Ø 10 mm hole to accept the detergent hose & filter. The detergent hose connects to the unit via a tip inserted between hose and check valve. The incoming 1/2″ water connection is to a 1.5 M long s/steel braded hose (F 1/2″-F 3/4″) supplied.

The outer casing houses a red lever handle (the water inlet valve) and a black, two position lever handle (the detergent flow). Position one is used for the washing operation (which adds detergent), position two is used for the rinsing operation (which prevents detergent flow).  A bag of 14 colour-coded nozzles/valves are also provided, to allow various % detergent dilution levels between 0.5%-10.9% to be set. (Inserted between detergent hose and check valve inside unit).

Visual

Sterilizing Unit.TOURNUS_300_rvb
Visual

806462






Features

Sterilizing Unit.TOURNUS_300_rvb
Features

806462

  • Wall mounted sterilizing unit with hydraulic spray, for low pressure cleaning and sterilizing of surfaces and floors.
  • Designed for use with 2-6 bar water pressure.
  • Supplied with separate detergent can holding frame, for supporting a 5 Lt. container (max. load 10 Kg).
  • Features a 15 M length discharge hose & anti-shock spray gun c/w trigger handle (Diag. Ref. B).
  • 2 M length of detergent suction hose provided, with a weighted end filter.
  • Incoming 1/2″ water connection to a 1.5 M long s/steel braded hose (F 1/2″-F 3/4″) supplied.
  • Outer casing houses lever handle, for water inlet valve (Diag. Ref. A).
  • Outer casing also houses on/off lever handle for the detergent flow (Diag. Ref. C).
  • 14 colour-coded nozzles/valves are also provided, to allow various % detergent dilution levels.
  • Detergent hose connects to the unit via a tip inserted between hose and check valve.
  • Supplied with fixing screws, wall plugs, hose fibre gaskets and washers.
  • Maximum working water temperature 50 deg. C.
  • Detergent/ water dilution ratio adjustable between 0.5 % – 10.9 % (via colour coded nozzles/valves supplied).
  • Detergent dilution nozzles/valves are inserted between hose connection and check valve.
  • Model code – wall mounted sterilizing unit with hydraulic spray/ 1 x 5 Lt. container support frame –  (806 462).


Dimensions

Sterilizing Unit.TOURNUS_300_rvb
Dimensions.

806462

Model

806462

Description

Sterilizing Unit With Hydraulic Spray

Water Pressure (Bar)

2 – 6

Mounting Method

Wall Mounted

5 Lt. Detergent Container Support Frame

Included

Anti-shock spray gun c/w trigger handle
(Diag. Ref. B)

Included

Detergent Discharge Hose Length (M)

15

Water Connection Size

1/2 “

Water Connection Hose Type

1.5 M long S/Steel Braded Hose (F 1/2″-F 3/4″) – Supplied

Outer Casing  – Water Inlet Valve
(Diag. Ref. A)

Lever Handle (Red)

Outer Casing – Detergent Inlet Valve
(Diag. Ref. C)

Lever Handle (Black)

Detergent Dilution – Via Colour Coded Nozzles Supplied

0.5 % – 10.9 %

Unit Length (mm)

262

Unit Depth (mm)

110

Unit Height (mm)

390

Detergent Container Mounting Height – Below Unit (mm)

300



Options

Sterilizing Unit.TOURNUS_300_rvb
Bespoke Options (Available From Tournus).

sterilizing-unit---options

Model

605301

605302

Description

S/steel Wall Column, Integrated Sterilizing Unit With Hydraulic Spray.

S/steel Wall Column, Integrated Sterilizing Unit With Hydraulic Spray & TS200N Hand Wash Basin.

Water Pressure (Bar)

2 – 6

2 – 6

Mounting Method

Wall Mounted

Wall Mounted

5 Lt. Detergent Container Support Frame

Included Separate

Included Separate

Anti-shock spray gun c/w trigger handle
(Diag. Ref. B)

Included

Included

Discharge Hose Length (M)

15

15

Water Connection Size

1/2 “

1/2 “

Water Connection Hose Type

1.5 M long S/Steel Braded Hose (F 1/2″-F 3/4″) – Supplied

1.5 M long S/Steel Braded Hose (F 1/2″-F 3/4″) – Supplied

Outer Column – Water Inlet Valve
(Diag. Ref. A)

Lever Handle (Red)

Lever Handle (Red)

Outer Column – Detergent Inlet Valve
(Diag. Ref. C)

Lever Handle (Black)

Lever Handle (Black)

Detergent Dilution – Via Colour Coded Nozzles Supplied

0.5 % – 10.9 %

0.5 % – 10.9 %

Column Width (mm)

375

375

Column Depth (mm)

110

110

Column Height (mm)

1370 – 1870

1370 – 1870

Detergent Container Mounting Height (mm)

Adjacent Column Base

Adjacent Column Base
