Tournus wall shelves are designed in s/steel for back of house storage in a busy kitchen area. They are available in a range of lengths and types to suit locations and required storage loads.

Wall Mounted Shelves (4 Bar Type). Produced as an open frame wall shelf, these models consist of a 400 mm deep platform, made from 4 no. s/steel box section tubes, each 25 x 25 mm. They are supported on 2 or 3 no. support brackets depending on shelf length required. (2 brackets for shelves up to 2 M long, 3 brackets for shelves over 2 M long). Each support bracket accepts 3 screw fixings.

Wall Mounted Shelves (Solid Shelf Type With Welded Ends). The wall shelf features a 400 mm deep solid s/steel shelf with radius front down-stand, welded ends and a rear up-stand. When mounted on the support brackets (2 or 3 no. support brackets depending on shelf length required), a 40 mm clearance is created behind the rear up-stand to hide pipework that may be present.

Wall Mounted Shelves – Solid Shelf Type With Vertical Wall Runners/ Racks (Single & Double Tier Type). The 290 or 390 mm deep shelves are made as a solid s/steel shelf with radius front down-stand, welded ends and a 50 mm high rear up-stand. Single and double tier shelf versions are available with either 2 or 3 support brackets and  wall mounted runners/ racks dependent on length.  The shelf bracket engages into the vertical rear runners/ racks which are wall mounted.

Visual

Wall Mounted Shelves.TOURNUS_300_rvb
Visualwall-shelves---features-hig



Features

Wall Mounted Shelves.TOURNUS_300_rvb
Features

Wall Mounted Shelves – 4 Bar Type.
(400 mm Deep)

4-Bar-Features

  • Open frame wall shelf for general kitchen utensil storage.
  • Made of food quality stainless steel.
  • 400 mm deep open shelving platform, made from 4 no. s/steel box section tubes (25 x 25 mm).
  • Supported on 2 or 3 no. support brackets depending on shelf length required.
  • 2 shelf support brackets for shelves up to 2 M long, 3 shelf support brackets for shelves over 2 M long.
  • Each shelf support bracket accepts 3 screw fixings.
  • Available in 800, 1000, 1200, 1400, 1500, 1600, 1800, 2000 & 2200 mm long versions.
  • Maximum distributed load 150 kg.
  • Model Code 805 715 : O/all size 800 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 805 720 : O/all size 1000 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 805 721 : O/all size 1200 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 805 722 : O/all size 1400 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 805 726 : O/all size 1500 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 805 723 : O/all size 1600 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 805 724 : O/all size 1800 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 805 725 : O/all size 2000 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 805 727 : O/all size 2200 mm (l) x 400 mm (d) x 150 mm bracket height (h).



Wall Mounted Shelves – Solid Shelf Type With Welded Ends.
(400 mm Deep)

solid-shelf-features

  • 400 mm deep wall shelf in solid s/steel, with radius front down-stand, welded ends and a rear up-stand, for general kitchen equipment storage.
  • Made of food quality stainless steel.
  • 40 mm clearance provided behind the rear up-stand to hide pipework that may be present.
  • Supported on 2 or 3 no. support brackets depending on shelf length required.
  • 2 shelf support brackets for shelves up to 2 M long, 3 shelf support brackets for shelves over 2 M long.
  • Each shelf support bracket accepts 3 screw fixings.
  • Available in 800, 1000, 1200, 1400, 1500, 1600, 1800, 2000 & 2200 mm long versions.
  • Maximum distributed load 150 kg.
  • Model Code 509 769 : O/all size 800 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 509 751 : O/all size 1000 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 509 752 : O/all size 1200 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 509 753 : O/all size 1400 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 509 754 : O/all size 1500 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 509 755 : O/all size 1600 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 509 756 : O/all size 1800 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 509 757 : O/all size 2000 mm (l) x 400 mm (d) x 150 mm bracket height (h).
  • Model Code 509 758 : O/all size 2200 mm (l) x 400 mm (d) x 150 mm bracket height (h).



Wall Mounted Shelves – Solid Shelf Type With Vertical Wall Runners/ Racks.
(Single & Double Tier/ 290 & 390 mm Deep)

solid-shelf--with-racks-fea

  • Available as either 290 mm or 390 mm deep shelves and made as a solid s/steel shelf with radius front down-stand, welded ends and a 50 mm high rear up-stand, in single or double tier models.
  • Made of food quality stainless steel.
  • Single and double tier shelf versions supplied with either 2 or 3 support brackets and wall mounted runners/ racks, dependent on length.
  • The shelf bracket engages into the vertical rear wall mounted racks which are screw fixed.
  • Shelf height adjustment in 55 mm increments.
  • Single  tier shelf models available in 800, 1000, 1200, 1400, 1500, 1600, 1800, 2000 & 2200 mm long versions.
  • Double tier shelf models available in 800, 1000, 1200, 1400, 1500, 1600, 1800, 2000 & 2200 mm long versions.

Single Tier Shelf Models (290 mm deep) :

  • Model Code 509 971 : O/all size 800 mm (l) x 290 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 972 : O/all size 1000 mm (l) x 290 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 973 : O/all size 1200 mm (l) x 290 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 974 : O/all size 1400 mm (l) x 290 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 975 : O/all size 1500 mm (l) x 290 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 976 : O/all size 1600 mm (l) x 290 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 977 : O/all size 1800 mm (l) x 290 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 978 : O/all size 2000 mm (l) x 290 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 979 : O/all size 2200 mm (l) x 290 mm (d) x 315 mm (h) wall mounted rack height.

Single Tier Shelf Models (390 mm deep) :

  • Model Code 509 910 : O/all size 800 mm (l) x 390 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 911 : O/all size 1000 mm (l) x 390 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 912 : O/all size 1200 mm (l) x 390 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 913 : O/all size 1400 mm (l) x 390 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 914 : O/all size 1500 mm (l) x 390 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 915 : O/all size 1600 mm (l) x 390 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 916 : O/all size 1800 mm (l) x 390 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 917 : O/all size 2000 mm (l) x 390 mm (d) x 315 mm (h) wall mounted rack height.
  • Model Code 509 918 : O/all size 2200 mm (l) x 390 mm (d) x 315 mm (h) wall mounted rack height.

Double Tier Shelf Models (290 mm deep) :

  • Model Code 509 986 : O/all size 800 mm (l) x 290 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 987 : O/all size 1000 mm (l) x 290 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 988 : O/all size 1200 mm (l) x 290 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 989 : O/all size 1400 mm (l) x 290 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 990 : O/all size 1500 mm (l) x 290 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 991 : O/all size 1600 mm (l) x 290 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 992 : O/all size 1800 mm (l) x 290 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 993 : O/all size 2000 mm (l) x 290 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 994 : O/all size 2200 mm (l) x 290 mm (d) x 700 mm (h) wall mounted rack height.

Double Tier Shelf Models (390 mm deep) :

  • Model Code 509 925 : O/all size 800 mm (l) x 390 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 926 : O/all size 1000 mm (l) x 390 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 927 : O/all size 1200 mm (l) x 390 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 928 : O/all size 1400 mm (l) x 390 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 929 : O/all size 1500 mm (l) x 390 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 930 : O/all size 1600 mm (l) x 390 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 931 : O/all size 1800 mm (l) x 390 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 932 : O/all size 2000 mm (l) x 390 mm (d) x 700 mm (h) wall mounted rack height.
  • Model Code 509 933 : O/all size 2200 mm (l) x 390 mm (d) x 700 mm (h) wall mounted rack height.
