Quick Service Wall Benches.
Wall Benches (With Under Shelf).
CED’s Quick Service range of fully welded wall benches, corner wall benches and wall benches (with void), are constructed from sturdy 30 mm 430 gd. sq box section framing with durable 1.2 mm thick 304 gd. steel worktops and 1.2 mm thick 430 gd. under shelves as standard. Wall bench units are available in three depths and up to eight standard lengths.
Corner Wall Benches & Angled Corner Wall Benches.
Quick Service corner wall benches are also made in the same three depths as other straight wall benches. They are also available as left or right hand models, or as an angled corner in three popular depths.
Wall Benches (With Void).
A further choice of Quick Service wall benches with voids under – ideal for equipment storage – are also available in matching depths, with a selection of length options. Standard wall bench height is 900mm, to suit most kitchen area back counters.
General Specification. Each wall bench type has a solid steel worktop with 50 mm downstand to each edge, the worktop has a 50 mm(H) x 15 mm(D) upstand to the rear. Wall benches & corner wall benches feature a solid steel storage under-shelf below. The legs of the wall benches are fitted with adjustable height flanged feet, for securing the unit to a floor surface on site. All wall bench legs are inset 100 mm to the rear, to allow for service pipework behind. Wall bench legs are set inboard of the worktop 50 mm at each end.
Quick Service Wall Bench Types.
Wall Bench (With Under Shelf).
Visual.
Wall Bench (With Under Shelf).
Specification.
- Fully welded free standing, wall sited commercial s/steel wall bench with worktop.
- Worktop constructed in 304 gd (1.2 thk.) s/steel supported on 30 x 30 box section 430 gd (1.2 thk.) framework.
- Welded low level 430 gd (1.2 thk.) s/steel storage under-shelf.
- Available in 600, 900, 1000, 1200, 1400 , 1500, 1800 & 2100 mm popular lengths.
- Available in 600, 650 & 700 mm depths.
- Standard wall bench height is 900 mm – to suit most kitchen area back counters.
- Steel worktop features 50 mm down stand to each edge.
- 50 mm(H) splashback/ wall up stand to rear of worktop.
- Wall bench legs inset 100 mm to the rear, to allow for service pipework behind.
- Frame fitted with flanged levelling feet for mechanical fixing to floor surface.
- Wall bench height adjustment: -15/+35mm.
937 downloads
Wall Bench (With Under Shelf).
(600mm deep) Dimensions.
Model
|
QWB
661U
|
QWB
961U
|
QWB
1061U
|
QWB
1261U
|
QWB
1461U
|
QWB
1561U
|
QWB
1861U
|
QWB
2161U
|
Type
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
Length
|
600
(mm)
|
900
(mm)
|
1000
(mm)
|
1200
(mm)
|
1400
(mm)
|
1500
(mm)
|
1800
(mm)
|
2100
(mm)
|
Depth
|
600
(mm)
|
600
(mm)
|
600
(mm)
|
600
(mm)
|
600
(mm)
|
600
(mm)
|
600
(mm)
|
600
(mm)
|
Worktop
Height
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
Rear
Upstand
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
1 Shelf
|
Included
|
Included
|
Included
|
Included
|
Included
|
Included
|
Included
|
Included
|
Height
Adjust.
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
Weight
|
14 (kg)
|
19 (kg)
|
20 (kg)
|
23 (kg)
|
27 (kg)
|
28 (kg)
|
33 (kg)
|
38 (kg)
|
Wall Bench (With Under Shelf).
(650mm deep) Dimensions.
Model
|
QWB
6651U
|
QWB
9651U
|
QWB
12651U
|
QWB
15651U
|
QWB
18651U
|
QWB
21651U
|
Type
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
Length
|
600
(mm)
|
900
(mm)
|
1200
(mm)
|
1500
(mm)
|
1800
(mm)
|
2100
(mm)
|
Depth
|
650
(mm)
|
650
(mm)
|
650
(mm)
|
650
(mm)
|
650
(mm)
|
650
(mm)
|
Worktop
Height
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
Rear
Upstand
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
1 Shelf
|
Included
|
Included
|
Included
|
Included
|
Included
|
Included
|
Height
Adjust.
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
Weight
|
15 (kg)
|
20 (kg)
|
25 (kg)
|
30 (kg)
|
35 (kg)
|
40 (kg)
|
Wall Bench (With Under Shelf).
(700mm deep) Dimensions.
Model
|
QWB
671U
|
QWB
971U
|
QWB
1071U
|
QWB
1271U
|
QWB
1571U
|
QWB
1871U
|
QWB
2171U
|
Type
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
W.Bench
1 Shelf
|
Length
|
600
(mm)
|
900
(mm)
|
1000
(mm)
|
1200
(mm)
|
1500
(mm)
|
1800
(mm)
|
2100
(mm)
|
Depth
|
700
(mm)
|
700
(mm)
|
700
(mm)
|
700
(mm)
|
700
(mm)
|
700
(mm)
|
700
(mm)
|
Worktop Height
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
Rear
Upstand
|
50×15
(mm)
|
50×15
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
1 Shelf
|
Included
|
Included
|
Included
|
Included
|
Included
|
Included
|
Included
|
Height
Adjust.
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
Weight
|
15 (kg)
|
21 (kg)
|
22 (kg)
|
26 (kg)
|
32 (kg)
|
37 (kg)
|
43 (kg)
|
General Layout Drawings.
All Wall Benches (With Under Shelf).
Specification Sheet & User Guide.
All Wall Benches (With Under Shelf).
Corner Wall Bench.
Visual.
Angled Corner Wall Bench.
Corner Wall Bench.
Specification.
- Fully welded free standing, wall sited commercial s/steel corner wall bench with worktop.
- Worktop constructed in 304 gd (1.2 thk.) s/steel supported on 30 x 30 box section 430 gd (1.2 thk.) framework.
- Welded low level 430 gd (1.2 thk.) s/steel storage under-shelf.
- Left hand & right hand corner versions available.
- Available in 600, 650 & 700 mm popular lengths.
- Available in 600, 650 & 700 mm depths.
- Standard corner wall bench height is 900 mm – to suit most kitchen area back counters.
- Steel worktop features 50 mm down stand to each edge.
- 50 mm(H) splashback/ wall up stands to rear of corner worktop.
- Corner wall bench legs inset 100 mm to the rear, to allow for service pipework behind.
- Frame fitted with flanged levelling feet for mechanical fixing to floor surface.
- Wall bench height adjustment: -15/+35mm.
Angled Corner Wall Bench.
Specification.
- Fully welded free standing, wall sited angled corner commercial s/steel wall bench with worktop.
- Worktop constructed in 304 gd (1.2 thk.) s/steel supported on 30 x 30 box section 430 gd (1.2 thk.) framework.
- Welded low level 430 gd (1.2 thk.) s/steel storage under-shelf.
- Available in 600, 650 & 700 mm popular depths (O/all plan size 1000 x 1000mm).
- Standard corner wall bench height is 900 mm – to suit most kitchen area back counters.
- Steel worktop features 50 mm down stand to each edge.
- 50 mm(H) splashback/ wall up stands to rear L/H & R/H side of worktop.
- Corner wall bench legs inset 100 mm to the rear, to allow for service pipework behind.
- Frame fitted with flanged levelling feet for mechanical fixing to floor surface.
- Wall bench height adjustment: -15/+35mm.
Corner Wall Bench.
(600mm, 650mm, 700mm deep) Dimensions.
Model
|
QCWB
66LH
|
QCWB
66RH
|
QCWB
6565LH
|
QCWB
6565RH
|
QCWB
77LH
|
QCWB
77RH
|
Type
|
L/H Corner
W.Bench
1 Shelf
|
R/H Corner
W.Bench
1 Shelf
|
L/H Corner
W.Bench
1 Shelf
|
R/H Corner
W.Bench
1 Shelf
|
L/H Corner
W.Bench
1 Shelf
|
R/H Corner
W.Bench
1 Shelf
|
Length
|
600
(mm)
|
600
(mm)
|
650
(mm)
|
650
(mm)
|
700
(mm)
|
700
(mm)
|
Depth
|
600
(mm)
|
600
(mm)
|
650
(mm)
|
650
(mm)
|
700
(mm)
|
700
(mm)
|
Worktop
Height
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
Corner
Type
|
Left
Hand
|
Right
Hand
|
Left
Hand
|
Right
Hand
|
Left
Hand
|
Right
Hand
|
Rear
Upstands
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
1 Shelf
|
Included
|
Included
|
Included
|
Included
|
Included
|
Included
|
Height
Adjust.
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
Weight
|
14 (kg)
|
14 (kg)
|
15 (kg)
|
15 (kg)
|
17 (kg)
|
17 (kg)
|
Angled Corner Wall Bench.
(600mm, 650mm, 700mm deep) Dimensions.
Model
|
QACWB
66
|
QACWB
6565
|
QACWB
77
|
Type
|
Angled Corner
W.Bench
1 Shelf
|
Angled Corner
W.Bench
1 Shelf
|
Angled Corner
W.Bench
1 Shelf
|
Length
|
1000
(mm)
|
1000
(mm)
|
1000
(mm)
|
Depth
|
600
(mm)
|
650
(mm)
|
700
(mm)
|
Worktop
Height
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
Corner
Type
|
Angled
|
Angled
|
Angled
|
Rear
Upstands
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
1 Shelf
|
Included
|
Included
|
Included
|
Height
Adjust.
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
Weight
|
29 (kg)
|
30 (kg)
|
30 (kg)
|
General Layout Drawings.
All Corner Wall Benches.
Specification Sheet & User Guide.
All Corner Wall Benches.
Wall Bench (With Void).
Visual.
Wall Bench (With Void).
Specification.
- Fully welded free standing, wall sited commercial s/steel wall bench with worktop.
- Worktop constructed in 304 gd (1.2 thk.) s/steel supported on 30 x 30 box section 430 gd (1.2 thk.) framework.
- Void underneath replaces s/steel storage under-shelf – to accommodate under-counter equipment.
- U shaped horizontal tie bar fitted @ 250mm (H) between rear legs, within void.
- Available in 900, 1200 & 1800 mm popular lengths.
- Available in 600, 650 & 700 mm depths.
- Wall bench height is 900 mm – to suit most kitchen area back counters.
- Steel worktop features 50 mm down stand to each edge.
- 50 mm(H) splashback/ wall up stand to rear of worktop.
- Wall bench legs inset 100 mm to the rear, to allow for service pipework behind.
- Frame fitted with flanged levelling feet for mechanical fixing to floor surface.
- Wall bench height adjustment: -15/+35mm.
- 600mm (D) models have a 575mm (D) void
- 650mm (D) models have a 625mm (D) void
- 700mm (D) models have a 675mm (D) void
Wall Bench (With Void).
(600mm, 650mm, 700mm deep) Dimensions.
Model
|
QWB
96V
|
QWB
126V
|
QWB
186V
|
QWB
1265V
|
QWB
127V
|
Type
|
W.Bench
With Void
|
W.Bench
With Void
|
W.Bench
With Void
|
W.Bench
With Void
|
W.Bench
With Void
|
Length
|
900
(mm)
|
1200
(mm)
|
1800
(mm)
|
1200
(mm)
|
1200
(mm)
|
Depth
|
600
(mm)
|
600
(mm)
|
600
(mm)
|
650
(mm)
|
700
(mm)
|
Worktop
Height
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
900
(mm)
|
Void Size (mm)
|
740 (L)
575 (D)
850 (H)
|
1040 (L)
575 (D)
850 (H)
|
1640 (L)
575 (D)
850 (H)
|
1040 (L)
625 (D)
850 (H)
|
1040 (L)
675 (D)
850 (H)
|
Rear
Upstand
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
50×15
(mm)
|
Rear Tie Bar Height (mm)
|
250
|
250
|
250
|
250
|
250
|
Height
Adjust.
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
-15/+35
(mm)
|
Weight
|
16 (kg)
|
19 (kg)
|
26 (kg)
|
21 (kg)
|
21 (kg)
|
General Layout Drawings.
All Wall Benches (With Void).
Specification Sheet & User Guide.
All Wall Benches (With Void).
